产品介绍
1. Streamlined appearance design, elegant and generous
2. The working device bucket can be set level automatically, computer is adopted to optimize design, high efficiency
3. New sealing cab, Grammer seat, the operating environment is more comfortable
4. Can allocate many kinds of selectante assembly such as wooden fork, pipe fork, grass fork, stone bucket, enlarged bucket, plow, fork etc, to meet the needs of various working states.
技术参数
| Specification LQ928 | |
| Rated capacity | 1.5m³; bucket |
| Rated weight | 2500kg |
| Operating weight | 6500kg |
| Performance of bucket being set level | Yes |
| Max. breakout force | 70KN |
| Max. drawbar pull | 45KN |
| Max. grade ability | 38° |
| Total of three time:lifting dumping lowering | 9.7m |
| Max.dump height | 3.2m |
| Max.dump reach | 1084mm |
| Min. ground clearance | 310mm |
| Wheel base | 2680mm |
| Tread | 2050mm |
| Overall dimensions (length*width*height) | 6510*2290*2850mm |
| Engine | Xichai |
| Model | 4DX22-96 |
| Pattern | inline,water cooled,dir.inject,fourstrokees |
| Max.torsion | 261Nm |
| Rated power | 70KW |
| Specified rotational speed | 2400r/min |
| Transmission | 280Gearbox seperated from torque converter |
| Model of torque device | YJ280 |
| Pattern | 3-element,single stage |
| Pattern of gearboxes | FULL-powershift,countersaft type |
| Number of great shift | 4forward,2 reverse |
| Max.travel speed | 30km/h |
| Main reducer type | arc taper gear moderation of first grade |
| Pattern of wheelside moderation | planet gear moderation of single |
| Type size | 16/70-24 |
| Steering angle(each direction) | 35°±1 |
| Min.turning radius(outside of bucket | 4500mm |
| Parking brake | Soft axle control,outside bunch drum type |
| Fuel capacity | 80L |
| Pressure of working hydraulic system | 160kgf/cm 2 |
| Basic specification | |
| Model | LQ928 |
| Engine Model | 4DX22-96 |
| Rated Power (KW) | 70KW |
| Rated capacity | 1.3m³ |
| Standard Configuration | Mechanical control |
| Payment Term | 100% paid by T/T---30% paid as down payment when contract signed; the balance of 70% to be paid before shipment |
| Validity of Quotation | One Months |
