产品介绍
标准配置：意大利进口静液压系统，电控先导，快换，可调仪表，可调座椅，瓦尔塔电瓶，帕金斯发动机，液压专用桥，26X12.00-16真空轮胎。
技术参数
| Whole drive system | Italy hydrostatic driving system | |
| Speicification | Overall weight(kg) | 1500 |
| L×W×H（mm） | 3690×1050×2300 | |
| Rated bucket capacity(m3) | 0.2 | |
| Rated load(kg) | 600 | |
| Dump height(mm) | 1930 | |
| Dump distance(mm) | 600 | |
| Wheelbase(mm) | 1330 | |
| Thread(mm) | 1200 | |
| Total time(s) | 8 | |
| Engine | Model | Perkins403D-11 |
| Type | Direct injection, Horizontal, Water-cooled, Three stroke | |
| Rated power（KW） | 18.4KW | |
| Rated speed(r/min) | 2200 | |
| Working pump | Italy- HFP2NP28E | |
| Min turning radius(mm) | 1550mm | |
| Controller | Type | USA-CL442 master |
| Flow | Flow | 30lpm |
| Tires | Standard tires | 26*12.00-12 |
| Stand bucket | Width (mm) | 1120 |
