1.3m3

Rated weight 额定载重量

2000kg

Transportation 尺寸

6500×2260×2855mm

Wheel base 轴距

2530mm

Tread 轮距

1635mm

Max. breakout force ##掘起力

48.87KN

Max. dumping height ##卸载高度

3330mm

Dump distance 卸载距离

885mm

Total time 三项和时间

11.3s

Operating weight 整机操作重量

5500kg

YUNNEI YN38GBZ

Pattern 型式

Inline, water-cooled, 4-stroke, direct injection直列，水冷，4冲程，直喷

Rated power/Speed 额定功率/转速

76KW/2400 rpm

Max. torque ##扭矩

275/261.7N.m

YJ280

Pattern 型式

3-element single stage单极三原件

Transmission type 传动类型

Full-power shift, countershaft type定轴常啮合式动力换挡

Number of gear 档位数

2 forward, 2 reverse2进2退

Max. travel speed ##车速

24km/h

Axle 车桥

JINLITE

Main reducer pattern 主传动型式

Arc taper gear, model ration of first grade圆弧圆锥齿轮一级减速

Pattern of wheelside moderation轮边减速型式

Planet gear moderation of single一级行星减速

Tire size 轮胎尺寸

16/70-20

Steering systemPattern 转向系统型式

Articulated and hydraulic steering铰接全液压转向

Min. turning radius(outside of bucket)##小转弯半径（外铲斗）

4500mm

Max. turning angle ##转向角

35°±1

CBF25

Displacement 排练

20ml/r

System working pressure 系统工作压力

16MPa

Distribution device model 分配阀型号

DF20.2C

Air assisted oil disc on four wheel 气顶油钳盘式四轮制动

Parking brake type 停车制动型式

Soft axle control, outside bunch drum type 软轴操纵外束型鼓式
