FEATURES
1.High reliability and productivity;
2.Torque converter and counter-shafe transmission gearbox.assemnled separately,higher reliability,easier maintenance;
3.Fully hydraulic steering system,power shift transmission,easier operation;
4.Bucket can be leveled automatically,optimized working device,higher productivity ;
5.Various working devives of attachment are available ,such as log clamp,pipe clamp,grass fork,plowore bucket ,loose bucket,fork etc,to meet different need.
SPECIFICATION 参数
Rated capacity 斗容 |
0,75 m³ |
Rated load 额定载重量 |
1600kg |
Transportation 尺寸 |
5400x1760x2600mm |
Wheel base 轴距 |
2070mm |
Tread 轮距 |
1430mm |
Max. breakout force ##掘起力 |
43 KN |
Dump Clearance at Full Height
Discharge 卸载高度 |
2900 mm |
Total time 三项和时间 |
13s |
Operating weight 整机操作重量 |
3800kg |
Engine 发动机
Model 型号 |
YUNNEI YN27 |
Pattern 型式 |
Inline, water-cooled, 4-stroke, direct injection直列，水冷，4冲程，直喷 |
Rated power/Speed 额定功率/转速 |
42 KW/2400 rpm |
Torque converter and transmission system 变矩器&传动系统
Pattern 型式 |
3-element single stage 单极三原件 |
Transmission type 传动类型 |
Full-power shift, countershaft type 定轴常啮合式动力换挡 |
Number of gear 档位数 |
2 forward, 2 reverse 2进2退 |
Max. travel speed ##车速 |
24km/h |
Axle 车桥 |
WEI XU |
Main reducer pattern 主传动型式 |
Arc taper gear, model ration of first grade 圆弧圆锥齿轮一级减速 |
Pattern of wheelside moderation 轮边减速型式 |
Planet gear moderation of single 一级行星减速 |
Tire 轮胎
Steering system 转向系统
Pattern 型式 |
Articulated and hydraulic steering铰接全液压转向 |
Min. turning radius(outside of bucket) ##小转弯半径（外铲斗） |
3400mm |
Max. turning angle##转向角 |
35°±1 |
Implement hydraulic system 工作液压系统
Implement pump工作泵型号 |
CBF32 |
Distribution device model 分配阀型号 |
DF15.2C |
Brake system制动系统
Brake type 制动类型 |
Air assisted oil disc on four wheel 气顶油钳盘式四轮制动 |
Parking brake type 停车制动型式 |
Soft axle control, outside bunch drum type 软轴操纵外束型鼓式 |
