Specifications
7350×3600×3450
Wheelbase (mm)轴距
3200
Wheel track (mm)轮距
2240
Height of shovel blade (mm)铲刀高度
1000
Weight of complete machine (t)整机质量
15.5
Maximum lift height of dozer blade蕞大提升高度
1060
Maximum down depth of dozer blade(mm)蕞大铲土深度
400
铲刀宽度
3600mm
Gradeability (°)爬坡能力
25
Engine
STEYR WD10G240E21潍柴斯太尔（国二）
Pattern型式
Turbocharger, vertical, water-cooled, 4-stroke, direct injection 直列 水冷 四冲程 增压
Rated power功率
175KW
Specified rotational speed转速
2000r/min
Max. torque蕞大扭矩
860N.m
Min. fuel consuming rate油耗
126g/kw.h
Total displacement排量
9.726L
Fuel柴油标号
0# or 10# diesel oil
Torque converter and transmission system
HANGZHOU ADVANCE or Beilian ZL60
3-element,single stage单极三元件
Transmission type传动型式
Full-powershift, countershaft type 行星式
Number of gear档位
2 forward,1 reverse 2进一退
Max. travel speed蕞大行驶速度
40km/h
Axle桥
Feicheng YUNYU
Main reducer type主传动形式
Arc taper gear, modelration of first grade 螺旋锥齿轮一级减速
Pattern of wheelside moderation轮边减速型式
Single stage planetary一级行星减速
Tire
23.5-25
Steering system
Full hydraulic steering system全液压转向
Min. turning radius(outside of bucket)蕞大转弯半径
7268mm
Max. turning angle蕞大转向角
35°±1
Implement hydraulic system
CBGJ2080/1010
Displacement排量
250L/min
System working pressure工作压力
20.3MPa
Distribution device model分配阀型号
DF32
Pilot valve model先导阀型号
DJS
Brake system
Air assisted oil disc on four wheel气顶油嵌盘式四轮刹车
Parking brake驻车制动动
Air cutting control inner eapand hoof 软轴式操控嵌盘式
